NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2235V

ROTOR DISC » RN2235V

Specification

Type

Vented

Outter Ø

285

Num. of holes

5

Hole Ø:

13

Disc Thickness (Max)

17

Disc Thickness (Min)

15.4

Height

46.4

Centering Diameter

58

Pitch Circle Ø

100

Front/Rear

Rear

Structure Material

G3000

Drum Ø:

148

Cross Reference

SUBARU

26700-FL000

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

SUBARU » Impreza

12.16~	1600	FB16	GK2	RN2454V	PN7805	RN2235V	PN7804
09.16~	1600	FB16A	GK3K	RN2454V	PN7805	RN2235V	PN7804
08.16~	1600	FB16A	GT2 JPN	RN2454V	PN7805	RN2235V	PN7804
08.16~	1600	FB16A	GT3 JPN	RN2454V	PN7805	RN2235V	PN7804
09.16~	1600	FB16A	GT3L	RN2454V	PN7805	RN2235V	PN7804
10.16~	2000	FB20	GT6 JPN	RN2454V	PN7805	RN2235V	PN7804
08.16~	2000	FB20C	GK7 JPN	RN2166V	PN7805	RN2235V	PN7804
08.16~	2000	FB20C	GK7 RHD	RN2454V	PN7805	RN2235V	PN7804
03.16~10.19	2000	FB20C	GT7 JPN	RN2454V	PN7805	RN2235V	PN7804
03.16~10.19	2000	FB20C	GT7 RHD	RN2454V	PN7805	RN2235V	PN7804

SUBARU » XV

05.17~	1600	FB16A	GT3 LH	RN2166V	PN7805	RN2235V	PN7804
05.17~	1600	FB16A	GT3 RH	RN2166V	PN7805	RN2235V	PN7804
03.17~	2000	FB20C	GT7	RN2166V	PN7805	RN2235V	PN7804
