ROTOR DISC » RN2224V

RN2224V

Specification

Type
Vented
Outter Ø
345
Num. of holes
5
Hole Ø:
16.5
Disc Thickness (Max)
30
Disc Thickness (Min)
28.5
Height
51
Centering Diameter
67.4
Pitch Circle Ø
120
Drum Ø:
160.5
Structure Material
G3000
Front/Rear
Front

Cross Reference

GM
15267103
GM
25946317
GM
92260109
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CADILLAC (GM)   »   CTS

01.08~09.13 3000 LFW 6D_69 RN2224V PN51008 RN2225V PN51007

CHEVROLET (GM)   »   Caprice / Lumina LHD

01.11~01.14 6000 L77 1E#19 6G1# RN2224V PN0831PN34002 PN0832 FN0696
01.07~12.09 6000 L98 8EP19 RN2224V PN34002PN0831 PN0832 FN0696
