ROTOR DISC » RN2203V

Specification

Type
Vented
Outter Ø
296
Num. of holes
5
Disc Thickness (Max)
28
Disc Thickness (Min)
25
Height
58.4
Centering Diameter
70
Pitch Circle Ø
110
Drum Ø:
139
Structure Material
G3000

Cross Reference

BENDIX
561730B
GM
569044
GM
90392559
GM
93182283
OEM
569045
OEM
90344650
OEM
90392559
OEM
90393496
OPEL
569016
OPEL
569044
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.96~12.01 3000 L81 6VR69 RN2203V PN0022 RN1063RN2204V PN0024 FN0519
08.01~07.03 2500 Y25DT B# RN2203V PN0022 RN1063 PN0024 FN0519
03.01~07.03 3200 Y32SE 0VM35 RN2203V PN0022 RN2204V PN0024 FN0519

Exemption from liability: the catalog data is advisory and can be used for reference only
