ROTOR DISC » RN2189V

Specification

Type
Vented
Outter Ø
239
Num. of holes
4
Disc Thickness (Max)
18
Disc Thickness (Min)
16
Height
34
Centering Diameter
65
Pitch Circle Ø
100
Drum Ø:
124.8
Structure Material
G3000

Cross Reference

VAG
5U0 615 301 B
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
04.11~ 1600 CCRA 5U RN2189VRN2188V PN0148WPN33010 DN1538RN2296 FN0554PN0019W
02.03~03.06 1800 BJY 5X9_F4 RN2189VRN2188V PN0830 DN1522 FN0534
06.02~03.06 2000 UQG 5X97G4 RN2189VRN2188V PN0830 DN1522 FN0534

Exemption from liability: the catalog data is advisory and can be used for reference only
