ROTOR DISC » RN31001V

RN31001V

Specification

Type
Vented
Outter Ø
288
Num. of holes
5
Disc Thickness (Max)
25
Height
64.5
Centering Diameter
67
Pitch Circle Ø
112
Front/Rear
Front
Disc Thickness (Min)
23
Drum Ø:
154
Structure Material
G3000

Cross Reference

MERCEDES-BENZ
2044210012
MERCEDES-BENZ
A 000 421 19 12
MERCEDES-BENZ
A 204 421 00 12
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MERCEDES-BENZ   »   C 180

06.12~01.14 1600 M 274.910 W204 RN1794DSETRN31001V PN0452W RN1708RN31002 PN0460W FN0672
11.09~01.14 1800 M 271.820 W204 RN1794DSETRN31001V PN0452W RN31002 PN0460W FN0672
09.07~ 1800 M 271.952 C204 RN31001V PN0452W RN31002 PN0460W
08.07~08.14 1800 M 271.952 S204 RN31001VRN1794DSET PN0452W RN31002RN1708 PN0460W FN0672
01.07~12.09 1800 M 271.952 W204 RN31001VRN1794DSETRN1463V PN0452W RN31002RN1708 PN0460W FN0672
04.10~01.14 2200 OM 651.913 W204 RN1794DSETRN31001V PN0452W RN1708RN31002 PN0460W FN0672

MERCEDES-BENZ   »   C 180 KOMPRESSOR

01.08~06.11 1600 M 271.910 W204 RN31001VRN1794DSET PN0452W RN1708RN31002 PN0460W FN0672
01.07~12.09 1800 M 271.952 W204 RN1794DSETRN31001V PN0452W RN31002RN1708 PN0460W FN0672

MERCEDES-BENZ   »   C 200

08.07~ 2200 OM 646.811 C204 RN31001V PN0452W RN31002 PN0460W FN0672
08.07~12.09 2200 OM 646.811 S204 RN31001V PN0452W RN31002 PN0460W FN0672
03.11~01.15 2200 OM 651.913 W204 RN31001V PN0452W RN1708RN31002 PN0460W FN0672

MERCEDES-BENZ   »   C 200d

01.07~12.09 2100 OM 646.811 W204 RN31001VRN1794DSET PN0452W RN31002RN1708 PN0460W FN0672

MERCEDES-BENZ   »   C 230

08.07~01.14 2300 M 272.921 C204 RN31001V PN0452W RN31002 PN0460W FN0672
