DRUM BRAKE » DN1756

Specification

Outter Ø
244
Num. of holes
4
Centering Diameter
63.5
Height
69.5
Pitch Circle Ø
108
Drum Ø
202.8
Structure Material
G3000
Hole Ø
13.8

Cross Reference

FORD
2094258
FORD
H1BC1126AA
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
07.20~ 1000 B#JA CE1 RN2390V PN51012 DN1756 PN0856FN0722
11.19~ 1000 B7JB CE1 RN2390V PN51012 DN1756 FN0722
05.17~ 1000 C10FD0X (100PS) CE1 RN2390V PN51012 DN1756 FN0722
05.17~ 1000 EcoBoost CE1 RN2390V PN51012 DN1756 PN0856FN0722
11.19~ 1000 M0JA (95PS) CE1 RN2390V PN51012 DN1756 FN0722
05.17~ 1100 Duratec TI-VCT CE1 RN2390V PN51012 DN1756 FN0722PN0856
05.17~ 1500 C15DSOX CE1 RN2390V PN51012 DN1756 PN0856FN0722
05.17~ 1500 XWJ# (120PS) CE1 RN2390V PN51012 DN1756 FN0722PN0856

Exemption from liability: the catalog data is advisory and can be used for reference only
