DRUM BRAKE » DN1746H

Specification

Outter Ø
243
Num. of holes
4
Centering Diameter
52.9-54.3
Height
81.1
Pitch Circle Ø
108
Drum Ø
203.1
Structure Material
G3000
Hole Ø
12.5
Notes
w/Wheel Bearing

Alternative

DN1746[NiBK]

Cross Reference

FORD
1151001
FORD
1213352
FORD
1315740
FORD
1416191
FORD
1468774
FORD
1507055
FORD
4329656
FORD
4345314
FORD
4376842
FORD
7S61 1113-AA
MAZDA
DD32-26-250
MAZDA
DD32-26-250A
MAZDA
DD32-26-250B
MAZDA
DD32-26-250C
MAZDA
DG40-26-250
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.02~06.12 1250 C12HDEZ (75PS) CBK RN1109V PN0337PN5495 DN1746H FN3421
11.01~06.12 1600 C16HDEZ (100PS) CBK RN1109V PN0337 DN1746H FN3421
05.02~06.08 1250 FUJ# (75PS) CBK RN1109V PN5495 DN1746H FN3421
03.03~06.08 1250 M7J# (70PS CBK RN1109V PN5495 DN1746H FN3421
09.02~09.08 1300 BAJA (60PS) CBK RN1109V PN5495 DN1746H FN3421
05.02~09.08 1300 C13LSEZ (70PS) CBK RN1109V PN5495PN0337 DN1746H FN3421
11.01~06.08 1400 C14HDEZ CBK RN1109V PN0337PN5495 DN1746H FN3421
11.01~06.08 1400 F6J# JH RN1109V PN5495PN0337 DN1746H FN3421
11.01~06.08 1600 C16HDEZ (100PS) CBK RN1109V PN5495PN0337 DN1746H FN3421
11.04~09.08 1600 HHJ# (90PS) CBK RN1109V PN5495 DN1746H FN3421
11.01~06.12 1400 C14HDEZ (75PS) CBK RN1109V PN5495 DN1746H FN3421
11.01~06.12 1600 C16HDEZ (100PS) CBK RN1109V PN5495 DN1746H FN3421
01.03~06.07 1250 FUJA DY RN1109V PN5495 DN1746H FN3421
01.03~06.07 1400 F6JA DY RN1109V PN5495 DN1746H FN3421
01.03~06.07 1400 FXJA DY RN1109V PN5495 DN1746H FN3421
01.03~01.07 1500 ZY-VE DY RN1512V PN5495 DN1746H FN3421
01.03~06.07 1600 FYJA DY RN1109V PN5495 DN1746H FN3421

Exemption from liability: the catalog data is advisory and can be used for reference only
