NiBK Brakes:: Application Cross Reference and Image for NiBK : DRUM BRAKE : DN1724

DRUM BRAKE » DN1724

Specification

Outter Ø

219

Num. of holes

4

Hole Ø

13.6

Centering Diameter

59

Height

53.3

Pitch Circle Ø

98

Drum Ø

185.4

Structure Material

G3000

Cross Reference

FIAT

4379680

FIAT

5974792

FIAT

7777842

VAG

SE022165201A

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

FIAT » Cinquecento

10.94~02.98	700	170 A.000			PN0287W	DN1724	FN0507
10.94~07.99	900	170 A1.000			PN0287W	DN1724	FN0507

FIAT » Nuova Panda

05.91~07.97	1000	156 A2.246	141AO		PN0233 PN0251	DN1724	FN0507 FN0601
05.91~	1100	156 C.046	141AK		PN0251	DN1724	FN0601
05.91~	1100	156 C.046	141AS		PN0251	DN1724	FN0601
05.91~	1100	156 C.046	141AW		PN0251	DN1724	FN0601
05.91~	1100	176 B2.000	141AK		PN0233 PN0251	DN1724	FN0601
05.91~	1100	176 B2.000	141AS		PN0251	DN1724	FN0601
05.91~	1100	176 B2.000	141AW		PN0233 PN0251	DN1724	FN0601
05.91~	1100	187 A1.000	141AK		PN0233 PN0251	DN1724	FN0601
05.91~	1100	187 A1.000	141AS		PN0251	DN1724	FN0601
05.91~	1100	187 A1.000	141AW		PN0251 PN0233	DN1724	FN0601
05.91~10.98	1100	TTL180C	141CZ		PN0233	DN1724	FN0507

SEAT » Marbella

01.87~12.93	800	08 NCA			PN0233	DN1724	FN0507
11.96~10.98	900	08 NCB	KAT		PN9201	DN1724	FN0507
01.87~12.93	900	09 NCA			PN0233	DN1724	FN0507
07.86~10.96	900	09 NCB			PN0233	DN1724	FN0507

SEAT » Terra

02.87~12.96	900	09 NCA			PN0233	DN1724	FN0507
01.90~12.95	900	09 NCB	KAT		PN0233	DN1724	FN0507
03.90~12.95	1300	MN			PN0233	DN1724	FN0507
10.90~12.95	1400	1W			PN0233	DN1724	FN0507
