NiBK Brakes:: Application Cross Reference and Image for NiBK : DRUM BRAKE : DN1703

DRUM BRAKE » DN1703

Specification

Outter Ø

219

Num. of holes

4

Hole Ø

13.2

Centering Diameter

59

Height

53

Pitch Circle Ø

98

Drum Ø

185

Structure Material

G3000

Cross Reference

FIAT

46448407

FIAT

5923606

FIAT

98601861

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

FIAT » Cinquecento

10.94~07.99

1100

176 B2.000

PN0287W

DN1703

FN0507

FIAT » Seicento

03.98~02.00	900	1170 A1.046	221SE		PN0287W	DN1703	FN0507
03.98~02.00	900	1170 A1.046	222SE		PN0287W	DN1703	FN0507
03.98~08.00	1100	176 B2.000 (SPI)	187	RN1385	PN0287W	DN1703	FN0507
09.00~01.10	1100	187A1.000 (MPI)	187	RN1385	PN0287W	DN1703	FN0507
