DRUM BRAKE » DN1676

DN1676

Specification

Outter Ø
262
Num. of holes
5
Hole Ø
12.9
Centering Diameter
108.3
Height
63.7
Pitch Circle Ø
139.7
Drum Ø
220
Structure Material
G3000

Cross Reference

GM
19171719
GM
30024672
SUZUKI
43511-65D10
SUZUKI
43511-65D10-000
SUZUKI
43511-67D01
SUZUKI
43511-67D01-000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHEVROLET (GM)   »   Tracker

01.99~01.05 2000 L34 CE103 RN1491V PN9301 DN1676DN1405 FN9958

SUZUKI   »   Grand Vitara

01.98~12.04 1600 G16B TB03V RN1491V PN9301 DN1676 FN9958
01.98~09.05 1600 G16B TD02V RN1491V PN9301 DN1676 FN9958
06.00~01.05 2000 J20A TL52W RN1140V PN9382 DN1676 FN9958
01.98~10.03 2000 RFM SQ420WD RN1140V PN9382 DN1405DN1676 FN9958
01.98~12.05 2500 H25A TD62V LHD RN1140V PN9382 DN1676 FN9958
01.98~12.05 2500 H25A TD62V RHD RN1140V PN9382 DN1676 FN9958
