DRUM BRAKE » DN1571

Specification

Outter Ø
269.5
Num. of holes
5
Centering Diameter
59
Height
61
Pitch Circle Ø
98
Drum Ø
228.3
Structure Material
G3000
Hole Ø
13.2

Cross Reference

FIAT
51860868
FIAT
51898123
FIAT
52015297
GM
95515120
GM
95524688
OPEL
05 68 002
OPEL
95524688
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.12~ 1400 843 A1.000 199LYB1B PN0187W DN1571 FN0781
01.15~ 1300 199 A3.000 263.122.1.5 RN1022V PN0187W DN1571 FN41002
01.12~01.18 1600 A16FDH B05 RN1022V PN0187W DN1571 FN41002

Exemption from liability: the catalog data is advisory and can be used for reference only
