DRUM BRAKE » DN1566

DN1566

Specification

Outter Ø
320
Num. of holes
5
Hole Ø
17.5
Centering Diameter
132
Height
104.9
Pitch Circle Ø
170
Drum Ø
280
Structure Material
G3000

Cross Reference

GM
9160399
OPEL
45 00 099
RENAULT
77 00 302 145
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

OPEL   »   Movano

09.00~06.10 1900 F9Q77# PN0128 DN1566 FN0543
05.04~ 2500 G9U 05 PN0128PN0215 DN1566 FN0543
09.01~01.04 2500 G9U720 PN0215PN0128 DN1566 FN0543
03.98~01.04 2500 S8U PN0215PN0128 DN1566 FN0543
03.98~01.04 2800 S9W PN0128PN0215 DN1566 FN0543

RENAULT   »   Master II

09.01~03.10 1900 F9Q 77# LCV / BUS /  TRUCK PN0215 DN1566 PN0216FN0543
03.00~11.03 1900 F9Q 78# LCV / BUS /  TRUCK PN0128PN0215 DN1566 FN0543PN0216
10.00~06.10 2200 G9T 7# LCV / BUS /  TRUCK PN0215 DN1566 FN0543PN0216
09.01~03.10 2500 G9U 7# LCV / BUS /  TRUCK PN0215 DN1566 PN0216FN0543
07.98~02.01 2500 S8U 7 LCV / BUS /  TRUCK PN0128PN0215 DN1566 FN0543PN0216
07.98~03.10 2800 S9W# LCV / BUS /  TRUCK PN0215PN0128 DN1566 FN0543PN0216

RENAULT   »   Master II Maxi

01.04~03.10 3000 ZD3# LCV / BUS /  TRUCK DN1566 PN0216FN0543

RENAULT   »   Master III

07.06~03.10 2500 G9U 6# LCV / BUS /  TRUCK PN0215 DN1566 FN0543PN0216
