DRUM BRAKE » DN1446

Specification

Outter Ø
230
Num. of holes
4
Centering Diameter
44-45.2
Height
59
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000
Hole Ø
M12x1.5
Notes
w/o Wheel Bearings

Cross Reference

KIA
0K30A-26-250A
KIA
0K30A26251A
KIA
0K30C26250A
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.99~08.02 1300 A3E DC2 RN1999V PN5232 DN1446 FN3347
01.99~07.02 1500 A5D SDN / HB PN0702PN5232 DN1499DN1446DN1511H FN3347
01.99~07.02 1500 A5E FDAD PN5232PN0702 DN1511HDN1499DN1446 FN3347

Exemption from liability: the catalog data is advisory and can be used for reference only
