DRUM BRAKE » DN1444

Specification

Outter Ø
233
Num. of holes
4
Hole Ø
14.5
Centering Diameter
56
Height
56.4
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000

Cross Reference

DAIHATSU
42431-87709
DAIHATSU
42431-87709-000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
06.89~05.00 1600 HD# A101S JPN PN6214 DN1444 FN0032
06.89~05.00 1600 HD# A101S RHD PN6214 DN1444 FN0032
01.87~01.93 1000 CB# G100S PN6186PN6214 DN1444 FN0030PN6185
02.97~06.98 1500 HE-EG G303 PN6340 DN1444 FN0035PN6353
07.98~07.02 1600 HD-EP G301 PN6340 DN1444 PN6353FN0035

Exemption from liability: the catalog data is advisory and can be used for reference only
