DRUM BRAKE » DN1424

DN1424

Specification

Outter Ø
372
Num. of holes
6
Centering Diameter
164
Height
139
Drum Ø
320
Structure Material
G3000
Hole Ø
15
Pitch Circle Ø
205

Cross Reference

HINO
42431-37100
HINO
42431-37101
TOYOTA
42431-37100
TOYOTA
42431-37101
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HINO   »   DUTRO

07.11~ 4000 N04C-T XZU710L RN2251VRN1448V PN1388PN4543 RN2252VDN1424RN1841V PN1388PN4543 FN0015FN2320FN4443
07.11~ 4000 N04C-T XZU710M RN1448VRN2251V PN4543PN1388 RN1841VRN2252VDN1424 PN4543PN1388 FN4443FN0015FN2320
07.11~ 4000 N04C-T XZU710R RN1448VRN2251V PN4543PN1388 RN2252VDN1424RN1841V PN1388PN4543 FN0015FN2320FN4443
08.11~ 4000 N04C-T XZU711 RN1448VRN2251V PN1388PN4543 DN1424RN1841VRN2252V PN4543PN1388 FN2320FN4443FN0015
07.11~ 4000 N04C-T XZU720R DN1425RN2251V PN4464FN0646 RN2252VDN1424
10.06~06.11 4000 W04D WU422L DN1425 FN0646 DN1424 FN0802 FN2320

HINO   »   Dutro WU-720

01.12~ 4000 W04D WU720L DN1425 FN0646 DN1424 FN0802 FN2320

TOYOTA   »   Dyna

05.17~ 4000 N04C XZU712 RN2251V PN1388 DN1424RN2252V PN1388 FN2320FN4443
07.11~ 4000 N04C-T XZU640 RN1448V PN1388PN4543 RN1841VDN1424 FN0015
07.11~ 4000 N04C-T XZU650 RN1448V PN1388PN4543 RN1841VRN2252VDN1424 PN1388 FN0015FN2320FN4443
07.11~ 4000 N04C-T XZU700 RN1448VRN2251V PN1388PN4543 DN1424RN1841VRN2252V PN1388 FN2320FN4443FN0015FN4466
07.11~ 4000 N04C-T XZU700A RN2251V PN1388 RN2252VDN1424 PN1388 FN4466
07.11~ 4000 N04C-T XZU710 RN2251VRN1448V PN1388PN4543 DN1424RN1841VRN2252V PN1388 FN0015FN4443FN2320
07.11~ 4000 N04C-T XZU710L RN1448VRN2251VDN1425 PN4464FN0646PN1388FN2329BL2329 RN2252VDN1217DN1424RN1841V FN2329FN0802 FN2320
12.06~ 4000 N04C-T XZU720 RN2251VRN1448V PN1388PN4543PN1553 DN1424RN2252VRN1841V PN1553PN1388 FN2320FN4443FN0015
10.01~02.08 4000 W04D WU410 DN1425 FN0646 DN1424
10.01~02.08 4000 W04D WU410R DN1425 FN0646 DN1424 FN0802 FN2320
05.99~06.04 4100 15B-FTE BU410 RN1448V PN1388 DN1424 FN2329BL2329 FN2320FN0015
05.99~06.04 4100 15B-FTE BU430 DN1425 FN0646 DN1424 FN2329BL2329 FN2320
05.99~10.06 4900 S05D XZU401 RN2251VRN1448VDN1425 FN0646PN1388PN4464 RN2252VDN1424DN1217 FN2329PN4464BL2329FN2296 FN2320FN0015
05.99~06.04 5300 J05C XZU340 DN1425RN1448V FN0646PN1388 DN1424DN1217 FN2329BL2329 FN0039FN2320FN0015
05.99~06.04 5300 J05C XZU350H DN1425 FN0646 DN1424 FN2329BL2329 FN2320FN4443
05.99~06.04 5300 J05C XZU400A DN1425 FN0646 DN1424 FN2329BL2329 FN2320
05.99~06.04 5300 J05C XZU410 RN1448VDN1425 FN0646PN1388 DN1217DN1424 BL2329FN2329 FN2320
05.99~06.04 5300 J05C XZU420 DN1425 FN0646 DN1424 FN2329BL2329 FN2320
05.99~02.08 5300 J05C XZU430 DN1425 FN0646 DN1424 FN2329BL2329 FN2320

TOYOTA   »   Toyo Ace Truck

07.11~ 4000 N04C-T XZU600W PN1388 DN1424RN2252V PN1388 FN4443
