NiBK Brakes:: Application Cross Reference and Image for NiBK : DRUM BRAKE : DN1404

DRUM BRAKE » DN1404

Specification

Outter Ø

297

Num. of holes

5

Hole Ø

12.7

Centering Diameter

108.3

Height

69.8

Pitch Circle Ø

139,7

Drum Ø

254.2

Structure Material

G3000

Cross Reference

SUZUKI

43511-52D00

SUZUKI

43511-52D00-000

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

SUZUKI » Grand Vitara XL-7

01.04~12.06	2000	RHW	JA420WD	RN1140V	PN9806	DN1404	FN9968
05.01~08.03	2700	H27A	TX92V LHD	RN1140V	PN9382	DN1404	FN9968
08.03~01.07	2700	H27A	TX92V LHD	RN1140V	PN9382	DN1404	FN9968
05.01~01.07	2700	H27A	TX92W RHD	RN1140V	PN9382	DN1404	FN9968
