DRUM BRAKE » DN1378

DN1378

Specification

Outter Ø
282
Num. of holes
4
Hole Ø
12.8
Centering Diameter
61.1
Height
81,5
Pitch Circle Ø
100
Drum Ø
220
Structure Material
G3000

Cross Reference

HONDA
42610-S6A-G00
HONDA
42610-SZY-010
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HONDA   »   Civic

12.01~09.06 1300 LDA-MF3/LDA1 ES9 JPN RN1089V PN8264 DN1378 FN5524
01.01~09.03 1400 D14Z6 EU7 RN1089V PN8103 DN1378 FN5524
09.00~09.03 1500 D15B EU1 JPN RN1089V PN8264 DN1378 FN5524

HONDA   »   Freed

05.08~08.16 1500 L15A GB3 JPN RN1089V PN8264 DN1378 FN5524
05.08~08.16 1500 L15A GB4 JPN RN1089V PN8264 DN1378 FN5524
05.08~08.16 1500 L15A7 GB3 SG RN1089V PN8264 DN1378 FN5524
10.11~09.16 1500 LEA-MF6 GP3 JPN RN1089V PN8868 DN1378 FN5524

HONDA   »   Mobilio

12.01~07.08 1500 L15A GB2 RN1089V PN8264 DN1378 FN5524
