DRUM BRAKE » DN1347

Specification

Outter Ø
215
Num. of holes
4
Hole Ø
13.6
Centering Diameter
66.8
Height
71.5
Pitch Circle Ø
114.3
Drum Ø
180
Structure Material
G3000

Cross Reference

MITSUBISHI
MB515476
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
05.88~08.91 1500 4G15 C62A RN1808 PN3089PN3285 DN1347 FN6712FN6707FN6670
09.87~10.91 1300 4G13 C51A RN1808 PN3089PN3285 DN1347 FN6670FN6707

Exemption from liability: the catalog data is advisory and can be used for reference only
