DRUM BRAKE » DN1323

Specification

Outter Ø
266
Num. of holes
5
Hole Ø
12.6
Centering Diameter
68
Height
63.3
Pitch Circle Ø
114.3
Drum Ø
228.6
Structure Material
G3000

Cross Reference

NISSAN
43206-5V000
NISSAN
43206-85E10
NISSAN
D3206-85E1J-NW
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.88~02.94 3000 VG30E J30 RN1036V PN2201 RN1583DN1323 FN1170
10.97~01.00 2000 SR20DE N30 RN1587V PN2261 DN1323 FN1240FN1170FN1193

Exemption from liability: the catalog data is advisory and can be used for reference only
