DRUM BRAKE » DN1280

DN1280

Specification

Outter Ø
242
Num. of holes
4
Hole Ø
14.7
Centering Diameter
55
Height
51.6
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000

Cross Reference

TOYOTA
42431-0D040
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Soluna Vios

01.02~ AXP4# DN1280
08.06~02.08 1300 2SZ-FE SCP41 RN1144V PN1472 DN1280 FN2342
10.02~08.06 1300 8A-FE AXP41 RN1144V PN1472 DN1280 FN2342
08.06~02.08 1500 3SZ-FE SCP42 RN1144V PN1472 DN1280 FN2342
10.02~02.08 1500 5A-FE AXP42 RN1144V PN1472 DN1280 FN2342
