DRUM BRAKE » DN1232

DN1232

Specification

Outter Ø
272
Num. of holes
5
Hole Ø
14.8
Centering Diameter
55.1
Height
56.3
Pitch Circle Ø
100
Drum Ø
228.5
Structure Material
G3000

Cross Reference

GM
88970141
TOYOTA
42431-01030
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

PONTIAC (GM)   »   VIBE I

01.02~01.08 1800 LV6(1ZZFE) SL26 RN1142V PN1470 DN1232 FN0704

TOYOTA   »   Matrix

01.02~01.08 1800 1ZZ-FE ZZE132 RN1142V PN1470 RN1440DN1232 PN1454FN0704 FN0614
01.02~01.08 1800 1ZZ-FE ZZE132L RN1142V PN1470 RN1440DN1232 FN0704 FN0614

TOYOTA   »   Voltz

05.02~02.04 1800 1ZZ-FE ZZE136 RN1142V PN1470 DN1232 FN0704
