DRUM BRAKE » DN1226

DN1226

Specification

Outter Ø
376
Num. of holes
5
Hole Ø
M14x1.5
Centering Diameter
126
Height
115.5
Pitch Circle Ø
167
Drum Ø
320
Structure Material
G3000

Cross Reference

TOYOTA
43512-36190
TOYOTA
43512-36191
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Coaster

01.93~07.99 3400 3B BB40 RN1479VDN1226 PN1388 BL2329FN2329 FN2298
01.93~12.16 4200 1H-Z HZB50R DN1226RN1479V PN1388PN1362 DN1217 FN2329BL2329 FN2320
