DRUM BRAKE » DN1201

DN1201

Specification

Outter Ø
237
Num. of holes
4
Centering Diameter
55
Height
65.5
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000
Hole Ø
14.6

Cross Reference

TOYOTA
42431-02030
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Corolla HB

05.97~01.00 1300 4E-FE EE111L RN1364V PN1194PN1322 RN1228DN1201 PN1321FN2354
