NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1531V

ROTOR DISC » RN1531V

Specification

Type

Vented

Disc Thickness (Max)

32

Num. of holes

5

Height

52.7

Centering Diameter

62

Front/Rear

Front

Pitch Circle Ø

114.3

Outter Ø

275

Drum Ø:

142

Cross Reference

TOYOTA

43512-30210

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Aristo

10.91~08.97

3000

2JZ-G#E

JZS147

RN1150V RN1531V

PN1231 PN1324 PN1228

RN1488V

PN1363

FN0567

TOYOTA » Crown Majesta

09.99~07.04	3000	2JZ-FSE	JZS177	RN1531V	PN1228		PN1421	FN0692
10.91~08.95	3000	2JZ-GE	JZS147	RN1531V	PN1228		PN1363	FN0567
08.95~09.99	4000	1UZ-FE	UZS151	RN1531V	PN1228		PN1363	FN0567
09.99~06.04	4000	1UZ-FE	UZS171	RN1531V	PN1228		PN1421
