ROTOR DISC » RN1510V

Specification

Type
Vented
Disc Thickness (Max)
28
Num. of holes
5
Height
76
Centering Diameter
67
Front/Rear
Front
Pitch Circle Ø
112
Outter Ø
312

Cross Reference

BENDIX
562202B
MERCEDES-BENZ
2204210912
MERCEDES-BENZ
A2204210912
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.99~09.06 5000 M 113.960 C215 RN1510VRN1135DSET PN0196W RN2456 PN0200WPN0344W FN0777
10.98~08.05 2800 M 112.922 W220 RN1510V PN0196W RN2456 PN0200WPN0344W FN0777
10.98~08.02 3200 M 112.944 W220 RN1510V PN0196W RN2456 PN0200W FN0777
10.02~10.05 3700 M 112.972 V220 RN1510V PN0196W RN2456 PN0344W FN0777
09.02~08.05 3700 M 112.975 W220 RN1510V PN0196W RN2456 PN0344W FN0777
10.02~10.05 3700 M 112.972 W220 RN1510V PN0196W RN2456 PN0344W FN0777
10.98~08.05 4300 M 113.941 W220 RN1135DSETRN1510V PN0196W RN2456 PN0200WPN0344W FN0777
10.98~08.05 5000 M 113.960 W220 RN1510VRN1135DSET PN0196W RN2456 PN0344WPN0200W FN0777

Exemption from liability: the catalog data is advisory and can be used for reference only
