NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1507V

ROTOR DISC » RN1507V

Specification

Type

Vented

Disc Thickness (Max)

30

Num. of holes

5

Height

56.8

Centering Diameter

58

Pitch Circle Ø

108

Front/Rear

Front

Outter Ø

316

Disc Thickness (Min)

28

Drum Ø:

149

Structure Material

G3000

Cross Reference

SUBARU

26300-AG001

SUBARU

26300AG000

SUBARU

26300AG02A

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

SUBARU » Forester

08.12~02.16	2000	EE20Z	SJDC RHD	RN1507V	PN7499	RN1542V	PN7803	FN0685
08.12~02.16	2000	EE20Z	SJDD LHD	RN1507V	PN7499	RN1542V	PN7803	FN0685
08.12~02.16	2000	FA20E	SJG JPN	RN1507V	PN7499	RN1542V	PN7803	FN0685
08.12~02.16	2000	FA20E	SJG#KK8	RN1507V	PN7499	RN1542V	PN7803	FN0685
02.16~01.19	2000	FA20E	SJG#KK8	RN1507V	PN7499	RN1542V	PN7803	FN0685
08.12~03.16	2000	FA20E	SJGK85 RHD	RN1507V	PN7499	RN1542V	PN7803	FN0685
03.16~01.19	2000	FA20E	SJGK85 RHD	RN1507V	PN7499	RN1542V	PN7803	FN0685
08.12~02.16	2000	FA20F	SJGL85	RN1507V	PN7499	RN1542V	PN7803	FN0685
08.12~01.19	2000	FB20B	SJ5#L7C	RN1122V RN1507V	PN7499 PN7460	RN1659 RN1542V	PN7501 PN7803	FN0685

SUBARU » Legacy

01.03~04.09	2000	EJ20X	BL5K	RN1530V RN1122V RN1507V	PN7499 PN0150S PN7460	RN2168V RN1509 RN1508V	PN0226S PN7415 PN7501	FN0742 FN0744
01.03~02.09	2000	EJ20X	BP5K	RN1122V RN1507V RN1530V	PN7460 PN7499	RN2168V RN1508V RN1509	PN7415 PN7501	FN0742 FN0744
01.03~05.09	2000	EJ20X/Y	BL5 JPN	RN1507V	PN7499	RN1508V	PN7415	FN0742
02.12~10.14	2000	FA20	BMG	RN1507V	PN7499	RN1660V	PN7803	FN0755
02.12~10.14	2000	FA20E	BRG	RN1507V	PN7499	RN1660V	PN7803	FN0755
02.09~05.12	2500	EJ25#	BM9 JPN	RN1010V RN1507V	PN7499 PN7460	RN1529 RN1660V	PN7501 PN7803	FN0625
02.09~04.12	2500	EJ25#	BR9 JPN	RN1122V RN1507V	PN7460 PN7499	RN1529 RN1660V	PN7501 PN7803	FN0625
03.03~04.09	2500	EJ255	BL9	RN1122V RN1507V	PN7460 PN7499	RN1508V RN1509 RN2168V	PN7501 PN7415 PN0226S	FN0742 FN0744
01.03~06.09	2500	EJ255	BL9AYCD US	RN1122V RN1507V	PN7460 PN7499	RN1509 RN1508V	PN7415 PN7501	FN0742
02.09~12.14	2500	EJ255	BM9(EURO)	RN1010V RN1507V	PN7460 PN7499	RN1660V RN1529	PN7501 PN7803	FN0625
05.03~05.09	2500	EJ255	BP9K	RN1507V RN1122V	PN7460 PN7499	RN1509 RN2168V RN1508V	PN0226S PN7415 PN7501	FN0742 FN0744
02.09~04.12	2500	EJ255	BR9	RN1122V RN1507V	PN7499 PN7460	RN1529 RN1660V	PN7501 PN7803	FN0625
02.12~10.14	2500	FB25A	BMM	RN1507V RN1010V RN1122V	PN7460 PN7499	RN1529 RN1660V	PN7803 PN7501	FN0755
01.03~06.09	3000	30D	BLEL	RN1507V	PN7499	RN1508V	PN7415	FN0742
01.03~04.09	3000	EZ30D	BLE JPN	RN1507V	PN7499	RN1508V	PN7415	FN0742
01.03~04.09	3000	EZ30D	BPE JPN	RN1507V RN1122V	PN7460 PN7499	RN1509 RN1508V	PN7501 PN7415	FN0742
01.03~04.09	3000	EZ30D	BPE RHD	RN1507V	PN7499	RN1508V	PN7415	FN0742
05.09~01.13	3600	EZ36D	BMF RH	RN1507V	PN7499	RN1660V	PN7803	FN0625

SUBARU » Legacy Outback

01.13~04.15	2000	EE20Z	BRD LHD EU	RN1507V	PN7499	RN1660V	PN7803	FN0755
03.08~05.09	2500	EJ255	BPH	RN1507V	PN7499	RN1508V	PN7415	FN0742
05.09~01.13	3600	EZ36D	BRF RH	RN1507V	PN7499	RN1660V	PN7803	FN0625
05.09~01.13	3600	EZ36D	BRFCLSU	RN1507V	PN7499	RN1660V	PN7803	FN0625
