ROTOR DISC » RN2150V

Specification

Type
Vented
Outter Ø
260
Num. of holes
6
Disc Thickness (Max)
24
Disc Thickness (Min)
21
Height
41
Centering Diameter
60
Pitch Circle Ø
100
Drum Ø:
125
Front/Rear
Front
Structure Material
G3000

Cross Reference

GM
52032950
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.12~12.18 1400 LQ5 1CH80 RN2150V PN0361 DN1663 FN0599
01.12~12.18 1800 LJ1 1CG80 RN2150V PN0361 DN1663 FN0599

Exemption from liability: the catalog data is advisory and can be used for reference only
