BRAKE SHOE » FN2294
Specification
Radius
160
Width
76
Thickness
5.5
Pcs In Set
4
Alternative
Cross Reference
AKEBONO
NR-1059
KASHIYAMA
K2294
TOYOTA
04494-36140
TOYOTA
04494-36141
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 05.82~01.93 | 2400 | 22R | RB20 | PN1388FN2294 | FN2266FN2295 | FN2298 | ||
| 08.84~08.88 | 2400 | 22R | RB26V | RN1479V | FN2294PN1388 | FN2295 | FN2298 | |
| 02.83~01.93 | 3400 | 3B | BB21 | PN1388FN2294 | FN2295 | FN2298 | ||
| 08.84~01.93 | 3400 | 3B | BB26V | PN1388FN2294 | FN2295 | FN2298 | ||
| 02.83~01.93 | 3400 | 3B | BB31 | PN1388FN2294 | FN2295 | FN2298 | ||
| 08.84~08.88 | 3400 | 3B | BB36V | FN2294PN1388 | FN2295 | FN2298 | ||
| 08.88~01.93 | 3700 | 14B | BB23 | PN1388FN2294 | FN2295 | FN2298 | ||
| 05.82~01.90 | 4000 | 2H | HB30 | PN1388FN2294 | FN2295 | FN2298 | ||
| 08.84~01.90 | 4000 | 2H | HB36V | FN2294PN1388 | FN2295 | FN2298 | ||
| 01.90~01.93 | 4200 | 1H-Z | HZB36V | PN1388FN2294 | FN2295 | FN2298 |
| 09.84~05.95 | 2000 | 3Y | YU60 | FN2296PN1388FN2294 | FN2265FN2295FN2297FN2296 | FN2298FN0019 | ||
| 01.86~09.93 | 2000 | 3Y | YU61D | FN2294 | FN2295 | FN2298 | ||
| 09.84~08.87 | 2000 | 3Y-P | YU80 | FN2294PN1388 | FN2295 | FN2298 | ||
| 10.89~05.95 | 3400 | BU68DH | FN2294 | FN2295 | FN2298 | |||
| 09.84~08.88 | 3400 | 13B | BU64 | PN1388FN2294 | FN2295 | |||
| 10.85~08.87 | 3400 | 13B | BU77 | FN2294PN1388 | FN2295 | |||
| 10.85~08.88 | 3400 | 13B | BU98 | PN1388FN2294 | FN2295 | |||
| 08.88~05.95 | 3700 | 14B | BU66 | RN1265V | FN2297PN1388FN2296FN2294PN1212 | FN2296FN2295FN2297 | FN2298 | |
| 08.88~11.98 | 3700 | 14B | BU66D | FN2295FN2294FN2296PN1388FN2297 | FN2295FN2297 | FN2298 | ||
| 08.88~05.95 | 3700 | 14B | BU66DH | FN2294 | FN2295 | FN2298 | ||
| 08.88~05.95 | 3700 | 14B | BU66H | PN1388FN2295FN2294 | FN2295 | FN2298FN0015 | ||
| 08.88~05.95 | 3700 | 14B | BU67 | PN1388FN2295FN2294 | FN2295 | FN2298 | ||
| 08.88~11.98 | 3700 | 14B | BU67D | FN2295FN2294 | FN2295 | FN2298 | ||
| 10.89~05.95 | 3700 | 14B | BU72DH | FN2294 | FN2295 | FN0015 | ||
| 10.89~10.92 | 3700 | 14B | BU72H | FN2294 | FN2295 | FN0015 | ||
| 10.89~05.95 | 3700 | 14B | BU73DH | FN2294 | FN2295 | FN2298 | ||
| 10.89~05.95 | 3700 | 14B | BU73H | FN2294 | FN2295 | FN2298 | ||
| 10.89~05.95 | 3700 | 14B | BU74 | FN2294 | FN2295 | FN0015 | ||
| 10.89~05.95 | 3700 | 14B | BU78 | PN1388FN2294 | FN2295 | FN2298 | ||
| 08.88~05.95 | 3700 | 14B | BU87 | PN1388FN2295FN2296FN2294 | FN2297FN2295 | FN2298 | ||
| 08.88~05.95 | 3700 | 14B | BU87V | FN2294PN1388 | FN2295 | FN2298 | ||
| 01.88~12.95 | 3700 | 14B | BU88 | PN1388FN2295FN2294 | FN2295 | FN0015 | ||
| 10.89~05.95 | 4000 | 1W | WU85 | FN2295PN1388FN2294 | FN2295 | FN0015FN2298 | ||
| 09.91~05.95 | 4000 | 1W | WU93 | PN1388FN2294 | FN2295 | FN2298 |
