NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1356V

ROTOR DISC » RN1356V

Specification

Num. of holes

8

Front/Rear

Front

Type

Vented

Outter Ø

293

Hole Ø:

13

Disc Thickness (Max)

40

Height

40

Centering Diameter

109

Pitch Circle Ø

140

Disc Thickness (Min)

38

Drum Ø:

170

Structure Material

G3000

Cross Reference

MAZDA

3513137

MAZDA

W53033251

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

MAZDA » Titan

04.00~06.04	3000	VS	WHS5T	RN1356V	PN4464		FN3409	FN3384
05.95~06.00	4000	TF	WGE4T	RN1356V	PN4464 FN3408 FN3390		FN3409 FN3408 FN3334 FN3389	FN3384
01.00~07.04	4100	TF	WHF5T	RN1356V	PN4464		FN3408 FN3409	FN3384
05.95~06.00	4300	YJ(4HF1)	WG3AT	RN1356V	FN3336 FN3390 PN4464		FN3409 FN3337 FN3408 FN3334	FN3389 FN3384
04.00~06.04	4300	YJ(4HF1)	WH35D	RN1356V	FN3408 PN4464		FN3408	FN3384
04.00~	4600	YM(4HG1)	WH65G	RN1356V	PN4464		FN3408	FN3384
