ROTOR DISC » RN1434V
Specification
Type
Vented
Disc Thickness (Max)
25
Num. of holes
5
Height
46.5
Centering Diameter
62
Front/Rear
Front
Pitch Circle Ø
114.3
Outter Ø
275
Drum Ø:
145
Disc Thickness (Min)
22
Structure Material
G3000
Cross Reference
TOYOTA
43512-0R010
TOYOTA
43512-42040
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 07.09~02.18 | 2400 | 2AZ-FXE | ANF10 | RN1434V | PN1524 | RN1433 | PN1522 | FN0621 |
| 07.09~01.12 | 2400 | 2AZ-FXE | ANF10L | RN1434V | PN1524 | RN1433 | PN1522 | FN0621 |
| 12.06~04.12 | 2400 | 2AZ-FE | AZE154H | RN1434V | PN1524 | RN1949 | PN1519 | |
| 12.06~04.12 | 2400 | 2AZ-FE | AZE156H | RN1434V | PN1524 | RN1949 | PN1519 |
| 04.10~12.16 | 2000 | 3ZR-FAE | ZRR70 | RN1434V | PN1524 | RN1229DN1211 | FN2371PN1449 | FN0567 |
| 08.08~04.10 | 2000 | 3ZR-FE | ZRR70 | RN1434V | PN1524 | RN1229 | PN1449 | FN0567 |
| 06.07~04.10 | 2000 | 3ZR-FAE | ZRR70 | RN1434V | PN1524 | RN1229DN1211 | FN2371PN1449 | FN0567 |
| 06.07~04.14 | 2000 | 3ZR-FAE | ZRR75 | RN1434V | PN1524 | RN1229 | PN1449 | FN0567 |
| 01.14~12.21 | 2000 | 3ZR-FAE | ZRR80 | RN1434V | PN1524 | DN1211RN1229 | FN2371PN1804 | FN0567 |
| 01.14~12.21 | 2000 | 3ZR-FAE | ZRR85 | RN1434V | PN1524 | RN1229 | PN1804 | FN0567 |
| 01.14~12.21 | 1800 | 2ZR-FXE | ZWR80 | RN1434V | PN1524 | RN1229 | PN1804 | FN0567 |
| 01.14~12.21 | 2000 | 3ZR-FAE | ZRR80 | RN1434V | PN1524 | DN1211 | FN2371 | |
| 01.14~12.21 | 2000 | 3ZR-FAE | ZRR85 | RN1434V | PN1524 | DN1211 | FN2371PN1804 | FN0567 |
| 04.11~ | 1800 | 2ZR-FXE | ZVW40W | RN1434V | PN1524 | RN1941 | PN1846 | FN0712 |
| 04.11~ | 1800 | 2ZR-FXE | ZVW41W | RN1434V | PN1524 | RN1941 | PN1846 | FN0712 |
