ROTOR DISC » RN2119

Specification

Type
Solid
Outter Ø
279
Num. of holes
5
Disc Thickness (Max)
10
Disc Thickness (Min)
8.5
Height
42.2
Centering Diameter
62
Pitch Circle Ø
114.3
Drum Ø:
154
Front/Rear
Rear
Structure Material
G3000

Cross Reference

TOYOTA
42431-21020
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.10~06.16 2500 2AR-FE AGT20 RN1241V PN1530 RN2119 PN1519
08.10~07.16 2500 2AR-FE AGT20L RN1241V PN1530 RN2119 PN1519

Exemption from liability: the catalog data is advisory and can be used for reference only
