ROTOR DISC » RN1314V

Specification

Type
Vented
Disc Thickness (Max)
28
Num. of holes
5
Height
58
Centering Diameter
72
Pitch Circle Ø
114.3
Front/Rear
Front
Outter Ø
276

Cross Reference

MAZDA
LA95-33-25X
MAZDA
LA953-32-51B
MAZDA
LB823325X
MAZDA
LB823325XA
MAZDA
S10H-33-25X
MAZDA
S10H-33-25XA
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
04.95~11.05 2000 FE SGEW RN1314V PN5376 PN5290 FN0779
04.95~11.05 2500 WL-T SGL5 RN1314V PN5376 PN5290
04.95~11.05 2500 WL-T SGLR RN1314V PN5376 PN5290 FN0779
04.95~11.05 2500 WL-T SGLW RN1314V PN5376 PN5290 FN0779
08.91~05.99 2500 G5-E LV5W RN1314V PN5376 PN5290
10.95~05.99 2500 WL-T LVLR RN1314V PN5376 PN5290 FN0779
10.95~05.99 2500 WL-T LVLW RN1314V PN5376 PN5290
08.92~06.99 3000 JE LV RN1314V PN5376PN3414 FN3378PN5290
11.89~05.99 3000 JE-E LVEW RN1314V PN5303PN3414PN5376 DN1410 PN5290FN3378

Exemption from liability: the catalog data is advisory and can be used for reference only
