ROTOR DISC » RN1282

Specification

Type
Solid
Disc Thickness (Max)
12.5
Num. of holes
6
Height
41
Centering Diameter
60
Pitch Circle Ø
100
Front/Rear
Front
Outter Ø
236
Disc Thickness (Min)
10.5
Drum Ø:
122
Structure Material
G3000

Cross Reference

BENDIX EUR
561158B
CHEVROLET
90008005
OPEL
569030
PONTIAC
90111242
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.91~03.99 1400 C14NZ RN1282RN1017V PN0021 FN0599FN0533
03.92~03.01 1400 C14SE RN1017VRN1282 PN0021PN0031 FN0533FN0599
09.91~03.99 1400 X14NZ RN1017VRN1282 PN0021 FN0599FN11622FN0533
02.96~08.00 1400 X14XE RN1017VRN1282 PN0021PN0189PN0031 FN0599PN0162FN0533
03.92~11.98 1600 C16NZ RN1282RN1017V PN0021 FN0533FN0599
03.92~12.94 1600 C16SE RN1282 PN0021PN0031 FN11622FN0533FN0599
03.92~11.98 1600 X16SZR RN1017VRN1282 PN0021PN0189 FN11622PN0162FN0533FN0599
01.85~03.93 1200 12NC RN1282 PN0234 FN0533
01.85~03.93 1200 12NV RN1282 PN0234 FN0533
01.85~03.93 1200 12NX RN1282 PN0234 FN0533
01.85~03.93 1200 E12GV RN1282 PN0234 FN0533
01.85~03.93 1400 C14NZ RN1282 PN0234 FN0533
03.93~10.00 1200 C12NZ RN1282 PN0021 FN0533
03.93~10.00 1400 C14NZ RN1282 PN0021 FN0533
09.94~10.00 1400 X14XE RN1282 PN0021 FN0533
07.89~02.93 1600 16SV RN1282 PN0234 FN11622
07.92~07.94 1700 17DR RN1282 PN0234 FN11622
10.86~02.93 2000 20NE RN1282 PN0234 FN11622
04.88~07.92 1400 14NV RN1282 PN0234 FN11622
09.88~05.93 1600 16SV RN1282RN1017V PN0234 FN11622
08.94~08.00 1200 C12N RN1282 PN0021 FN0533
08.94~08.00 1200 C12Z RN1282 PN0021 FN0533
08.94~08.00 1200 X12S RN1282 PN0021 FN0533
04.94~08.00 1600 C16XE RN1282 PN0021 FN0533
04.94~08.00 1600 X16XE RN1282 PN0021 FN0533
09.93~12.01 1700 X17D RN1282 PN0021 FN0533

Exemption from liability: the catalog data is advisory and can be used for reference only
