NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1260V

ROTOR DISC » RN1260V

Specification

Type

Vented

Disc Thickness (Max)

20

Num. of holes

6

Height

34

Centering Diameter

98

Pitch Circle Ø

122

Front/Rear

Front

Outter Ø

273.3

Hole Ø:

10.2

Disc Thickness (Min)

18

Drum Ø:

150

Structure Material

G3000

Cross Reference

MITSUBISHI

MB295968

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

MITSUBISHI » Canter

10.89~11.93	2800	4DR7	FB308	RN1260V	PN3347 PN3345		FN6655 FN6656	FN6600
10.89~11.93	2800	4DR7	FB328	RN1260V	PN3345 PN3346 PN3347		FN6655	FN6600
10.93~01.06	2800	4M40	FB511B	RN1260V	PN3347		FN6655	FN6600
10.85~11.93	3300	4D30	FE301	RN1260V	PN3347 PN3175		FN6602	FN6600
10.93~05.99	3600	4D36	FE516BT	RN1260V	PN3347		FN6602	FN4443
