ROTOR DISC » RN1249V
Specification
Type
Vented
Disc Thickness (Max)
22
Num. of holes
6
Height
72.9
Centering Diameter
94
Pitch Circle Ø
139.7
Front/Rear
Rear
Outter Ø
299.8
Drum Ø:
200
Disc Thickness (Min)
20.4
Structure Material
G3000
Cross Reference
MITSUBISHI
MR418067
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.00~09.06 | 3000 | 6G72 | V63W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 08.00~09.06 | 3000 | 6G72 | V73W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 10.06~ | 3000 | 6G72 | V93W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 03.09~03.18 | 3200 | 4M41 | V88W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 09.08~ | 3200 | 4M41 | V98W | PN1482 | RN1249V | PN3450PN1243 | FN0626FN0649 | |
| 09.99~11.05 | 3200 | 4M41-T | V68W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 09.99~11.06 | 3500 | 6G74 | V75W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 02.00~12.06 | 3800 | 6G75 | V77W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 10.06~11.12 | 3800 | 6G75 | V87W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 02.00~01.07 | 2500 | 4D56-T | V64W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 02.00~01.07 | 2500 | 4D56-T | V74W | RN1188V | PN3414 | RN1249V | PN3450 | |
| 09.06~ | 2800 | 4M40 | V96W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 02.00~12.06 | 2800 | 4M40-T | V76W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 05.03~01.07 | 3000 | 6G72 | V63W GL | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 02.00~12.06 | 3000 | 6G72 | V73W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 08.06~06.14 | 3000 | 6G72 | V83W | PN3414 | RN1249V | PN3450 | ||
| 08.06~02.15 | 3000 | 6G72 | V93W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 09.14~ | 3000 | 6G72 | V93W RUS | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 01.99~07.06 | 3200 | 4M41-T | V68W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 02.00~12.06 | 3200 | 4M41-T | V78W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 05.99~05.03 | 3200 | 4M41-T | V78W ER | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 09.06~08.14 | 3200 | 4M41-T | V88W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 01.99~11.05 | 3500 | 6G74 | V65W | RN1188V | PN3414 | RN1249V | PN3450 | |
| 01.99~11.05 | 3500 | 6G74 | V75W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 08.06~ | 3500 | 6G74 | V95W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 02.00~12.06 | 3800 | 6G75 | V77W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
| 10.06~10.12 | 3800 | 6G75 | V87W | RN1188V | PN3414 | RN1249V | PN3450 | FN0626 |
