NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1166V

ROTOR DISC » RN1166V

Specification

Type

Vented

Disc Thickness (Max)

20

Num. of holes

4

Height

41.2

Centering Diameter

60

Front/Rear

Front

Outter Ø

240

Drum Ø:

126

Pitch Circle Ø

100

Hole Ø:

14.3

Disc Thickness (Min)

17

Structure Material

G3000

Cross Reference

BENDIX

561248B

BENDIX

562290B

OPEL

0569021

OPEL

9195985

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

OPEL » Corsa C

09.00~11.06	1000	Z10XE		RN1166V	PN0361	DN1578 DN1852	FN11622 FN0533
11.00~11.03	1200	Z12XE	X01	RN1166V	PN0361	DN1852	FN11622
07.04~06.07	1200	Z12XEP		RN1166V	PN0361	DN1852 DN1578	FN0533 FN11622
09.00~11.06	1700	Y17DT		RN1166V	PN0361	DN1852 DN1578	FN0533 FN11622
