ROTOR DISC » RN1149

Specification

Type
Solid
Disc Thickness (Max)
10
Num. of holes
5
Height
75.1
Centering Diameter
72.2
Front/Rear
Rear
Pitch Circle Ø
127
Outter Ø
305
Disc Thickness (Min)
8,5
Drum Ø:
195
Structure Material
G3000

Cross Reference

BENDIX
562148B
CHRYSLER
2AMV8 666AA
CHRYSLER
52098 666
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.84~09.01 2100 J8S XJ PN8490PN0208 RN1149 PN0425FN0768PN0081
01.88~09.01 2500 ENC XJ PN0208PN8490 RN1149 PN0425FN0768PN0081
10.84~09.01 2500 EPE XJ PN8490PN0208 RN1149 FN0768PN0081PN0425
09.01~08.04 2700 ENF WG RN1147V PN0067PN0208 RN1149 PN0425
04.99~11.01 3100 EXA WG RN1147V PN0067PN0208 RN1149 PN0425
01.99~12.04 4000 ERH WJ__74 RN1147V PN0208PN0067 RN1149 PN0425
01.01~12.04 4700 EVA WGUP74 RN1147V PN0067PN0208 RN1149 PN0425
08.98~07.04 4700 EVA WJJP74 RN1147V PN0208PN0067 RN1149 PN0425

Exemption from liability: the catalog data is advisory and can be used for reference only
