ROTOR DISC » RN1115V

Specification

Type
Vented
Disc Thickness (Max)
18
Num. of holes
4
Height
43
Centering Diameter
55
Front/Rear
Front
Pitch Circle Ø
100
Outter Ø
258

Cross Reference

TOYOTA
43512-10100
TOYOTA
43512-10110
TOYOTA
43512-10170
TOYOTA
43512-16080
TOYOTA
43512-16130
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.90~08.94 1500 5E-FE EL43 RN1115V PN1077 DN1227H FN2321
01.91~08.95 1500 5E-FE EL44 RN1115V PN1077 DN1227H FN2321
08.95~07.99 1500 5E-FHE EL54 RN1115V PN1077 DN1202HDN1227H FN2321
04.91~08.95 1500 5E-FE EL44 RN1115V PN1077 DN1227H FN2321
09.96~03.99 1500 5E-FE EL54Convertible RN1097VRN1115V PN1077 DN1202H FN2321
08.95~07.99 1500 5E-FE EL54L RN1115VRN1097V PN1077 DN1202HDN1227H FN2321
05.97~04.03 1500 5E-FE EXZ10 RN1115V PN1077 FN2311
07.97~04.03 1500 5E-FE EXZ15 RN1115V PN1077 FN2313
03.90~12.95 1500 5E-FHE EXY10 RN1115V PN1077 DN1227H FN2321PN1178
01.89~12.96 1000 1E EP80L RN1115V PN1256PN1077 FN2321
12.89~09.92 1300 4E-FE EP82 RN1115VRN1097V PN1256PN1077 DN1227H FN2321
02.89~01.92 1300 4E-FTE EP82 RN1097VRN1115V PN1256PN1077 FN2321PN1178

Exemption from liability: the catalog data is advisory and can be used for reference only
