ROTOR DISC » RN1071V

Specification

Type
Vented
Disc Thickness (Max)
25
Num. of holes
5
Height
49.5
Centering Diameter
67
Front/Rear
Front
Pitch Circle Ø
112
Outter Ø
294
Disc Thickness (Min)
22.5
Drum Ø:
154.4

Cross Reference

BENDIX
561874B
BENDIX EUR
561874B
MERCEDES-BENZ
1244212412
MERCEDES-BENZ
A1244212412
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.92~07.96 3200 M 104.992 R124 RN1071V PN31022 RN1035 PN0006 FN0536FN0515
06.93~06.95 3200 M 104.992 W124 RN1071V PN31022 RN1035 PN0006 FN0515
06.93~02.95 3600 M 115.901 R124 RN1071V PN31022 PN0030WPN0006 FN0536
08.91~05.93 4200 M 119.975 W124 RN1071V PN31022 PN0006 FN0536
06.93~06.95 4200 M 119.975 R124 RN1071V PN31022 PN0006 FN0536
07.95~10.97 4200 M 119.985 W210 RN1071V PN31022 PN0030WPN0126W FN0515
06.93~06.95 5000 M 119.974 R124 RN1071V PN31022 PN0030W FN0536

Exemption from liability: the catalog data is advisory and can be used for reference only
