DRUM BRAKE » DN1139

DN1139

Specification

Outter Ø
262
Num. of holes
4
Hole Ø
12.6
Centering Diameter
100
Height
63
Pitch Circle Ø
139.7
Drum Ø
220
Structure Material
G3000

Cross Reference

SUZUKI
43511-78R00
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SUZUKI   »   Jimny

03.18~03.22 1500 K15B JB74V LHD RN1658 PN9816 DN1139 FN5524
03.22~ 1500 K15B JB74V LHD RN1658 PN9816 DN1139 FN5524
03.18~ 1500 K15B JB74V RHD RN1658 PN9816 DN1139 FN5524
