ROTOR DISC » RN1008V
Specification
Type
Vented
Num. of holes
5
Height
49.3
Centering Diameter
62
Front/Rear
Front
Pitch Circle Ø
114.3
Outter Ø
255
Disc Thickness (Min)
26
Hole Ø:
14,5
Disc Thickness (Max)
28
Drum Ø:
141
Structure Material
G3000
Cross Reference
BENDIX
561675B
TOYOTA
43512-33020
TOYOTA
43512-33050
TOYOTA
4351206010
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 06.91~08.98 | 2200 | 5S-FE | SXV10L | RN1008V | PN1322 | RN1486 | PN1321 | FN0633 |
| 06.91~01.02 | 2200 | 5S-FE | SXV20L | RN1009VRN1008V | PN1322PN1401PN1228 | RN1223RN1486 | PN1321PN1431FN2333 | FN0633 |
| 06.91~01.02 | 2200 | 5S-FE | SXV20R | RN1009VRN1008V | PN1228PN1401PN1322 | RN1486RN1223 | PN1431PN1321 | FN0633 |
| 12.96~09.01 | 2200 | 5S-FE | SXV20 | RN1008V | PN1322 | RN1486 | PN1321PN1431 | FN0633 |
| 12.96~09.01 | 2200 | 5S-FE | SXV20W | RN1008V | PN1322 | RN1486 | PN1321PN1431 | FN0633 |
| 05.98~04.01 | 2000 | 3S-FE | SXM10G | RN1008V | PN1322 | FN2339 | ||
| 05.98~08.02 | 2000 | 3S-FE | SXM15G | RN1008V | PN1322 | FN2339 | ||
| 01.98~09.04 | 2200 | 3C-TE | CXM10G | RN1008V | PN1322 | FN2339 |
| 05.95~12.01 | 2000 | 3S-FE | SXM10G | RN1008V | PN1322 | FN2339 | ||
| 01.96~05.01 | 2000 | 3S-FE | SXM15G | RN1008V | PN1322 | FN2339 | ||
| 09.97~05.01 | 2200 | 3C-TE | CXM10G | RN1008V | PN1322 | FN2339 |
