ROTOR DISC » RN1005V
Specification
Type
Vented
Disc Thickness (Max)
20
Num. of holes
6
Height
64.1
Centering Diameter
100
Front/Rear
Front
Outter Ø
288.6
Hole Ø:
10.6
Disc Thickness (Min)
18
Pitch Circle Ø
127
Drum Ø:
155
Structure Material
G3000
Cross Reference
BENDIX
561502B
OEM
43512YE020
OEM
B4351235190
TOYOTA
43512-35110
TOYOTA
43512-35190
VOLKSWAGEN
J4351235190
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.88~08.97 | 2400 | 22R-E | RN110L | RN1005V | PN1219PN1387 | DN1214 | FN2305 | |
| 08.88~08.97 | 2400 | 22R-E | RN110R | RN1005V | PN1219 | FN2305 | ||
| 08.84~12.89 | 2400 | 22R-EC | RN60LV- | RN1005V | PN1086 | DN1251 | FN2260 | |
| 01.88~12.89 | 2400 | 22R-EC | RN61 | RN1005V | PN1086PN1350 | FN2305 | ||
| 01.89~12.95 | 2800 | 3L | LN130L | RN1005V | PN1387PN1393PN1219 | FN2305 | ||
| 08.89~08.91 | 2800 | 3L | LN130R | RN1005VRN1056V | PN1351PN1387PN1219 | FN2305 | ||
| 08.88~11.95 | 3000 | 3VZ-E | VZN110 | RN1005V | PN1351PN1219PN1387 | DN1214 | FN2305 | |
| 08.89~06.91 | 3000 | 3VZ-E | VZN120 | RN1005VRN1056V | PN1219PN1351 | DN1214 | FN2305 | |
| 08.88~06.91 | 3000 | 3VZ-E | VZN130 | RN1005VRN1056V | PN1351PN1387PN1219 | DN1214 | FN2305 |
| 08.97~08.99 | 2000 | 1RZ-E | RZN167 | RN1005V | PN1387 | DN1214 | FN2305 | |
| 09.88~08.94 | 2000 | 3Y | YN100 | RN1005V | PN1387 | FN2305 | ||
| 08.88~08.97 | 2400 | 2L | LN110L | RN1005V | PN1219PN1387 | DN1214 | FN2305 | |
| 08.97~03.06 | 2400 | 2L | LN145 | RN1005V | PN1227 | FN2330 | ||
| 08.97~08.01 | 2400 | 2L-T | LN165L | RN1005V | PN1387 | DN1214 | FN2305 | |
| 08.97~12.03 | 2400 | 2L-T | LN165R | RN1005V | PN1387 | DN1214 | FN2305 | |
| 08.91~08.97 | 2400 | 2L-TE | LN108 | RN1005V | PN1219PN1387 | DN1214 | FN2305 | |
| 08.95~08.97 | 2400 | 2L-TE | LN112 | RN1005V | PN1387PN1219 | DN1214 | FN2305 | |
| 08.97~08.99 | 2400 | 2L-TE | LN165 | RN1005V | PN1387 | DN1214 | FN2305 | |
| 08.97~08.99 | 2400 | 2L-TE | LN170H | RN1005V | PN1387 | DN1214 | FN2305 | |
| 08.01~08.05 | 2500 | 2KD-FTV | KDN165 | RN1005V | PN1387 | DN1214 | FN2305 | |
| 08.01~08.05 | 2500 | 2KD-FTV | KDN170L | RN1005V | PN1387 | DN1214 | FN2305 | |
| 07.98~04.05 | 2700 | 3RZ-#E | RZN169L | RN1005V | PN1387 | DN1214 | FN2305 | |
| 07.98~04.05 | 2700 | 3RZ-FE | RZN169H | RN1005V | PN1387 | DN1214 | FN2305 | |
| 07.98~04.05 | 2700 | 3RZ-FE | RZN169R | RN1005V | PN1387 | DN1214 | FN2305 | |
| 08.91~08.97 | 2800 | 3L | LN107 | RN1005V | PN1387 | DN1214 | FN2305 | |
| 08.94~08.97 | 2800 | 3L | LN109 | RN1005V | PN1219PN1387 | DN1214 | FN2305 | |
| 08.97~03.06 | 2800 | 3L | LN166L | RN1005V | PN1387 | DN1214 | FN2305 | |
| 08.97~03.06 | 2800 | 3L | LN166R | RN1005V | PN1387 | DN1214 | FN2305 | |
| 08.97~03.06 | 3000 | 1KZ-TE | KZN165R | RN1005V | PN1387 | DN1214 | FN2305 | |
| 08.97~03.06 | 3000 | 1KZ-TE | KZN190 | RN1005V | PN1387 | DN1214 | FN2305 | |
| 01.89~01.14 | 3000 | 1KZ-TE | KZN205L | RN1005V | PN1219PN1387 | DN1214 | FN2305 | |
| 08.97~07.04 | 3000 | 5L | LN167 | RN1005V | PN1387 | DN1214 | FN2305 | |
| 01.01~12.04 | 3000 | 5L | LN200L | RN1005V | PN1387 | DN1214 | FN2305 | |
| 08.97~09.09 | 3000 | 5L-E | LN167R | RN1005V | PN1387 | DN1214 | FN2305 | |
| 11.97~07.04 | 3000 | 5L-E | LN172H | RN1005V | PN1387 | DN1214 | FN2305 | |
| 08.97~03.06 | 3000 | 5L-E | LN172R | RN1005V | PN1387 | DN1214 | FN2305 |
