ROTOR DISC » RN2829V

Image Not Available

Specification

Type
Vented
Outter Ø
345
Num. of holes
5
Hole Ø:
14
Disc Thickness (Max)
20
Disc Thickness (Min)
18
Height
42
Centering Diameter
65
Pitch Circle Ø
120
Drum Ø:
152
Front/Rear
Rear
Structure Material
G3000

Cross Reference

GAC MOTOR
3520006DRS0100
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

GAC   »   Trumpchi E8

11.23~ 2000 4B20L1 A09 RN2705V PN8083 RN2829V

GAC   »   Trumpchi E9

05.23~ 2000 4B20J2 A88 PN8006 RN2829V PN8072
05.23~ 2000 4B20J2 T88-G1 PN8006 RN2829V PN8072

GAC   »   Trumpchi GS8

12.21~ 2000 4B20J2 T60 PN8006 RN2829V PN8088

GAC   »   Trumpchi M8

09.22~ 2000 4B20J1 (400T) A88-ZD RN2705V PN8083PN8053 RN2706RN2829V PN8054PN8072
