ROTOR DISC » RN2815

Image Not Available

Specification

Type
Solid
Outter Ø
304
Num. of holes
5
Hole Ø:
13.8
Disc Thickness (Max)
12
Disc Thickness (Min)
10
Height
35.5
Centering Diameter
62.1
Pitch Circle Ø
114.3
Drum Ø:
147.5
Front/Rear
Rear
Structure Material
G3000

Cross Reference

CHANGAN
3502130-CH01
CHANGAN
F202F260303-0800
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHANGAN   »   X7 Plus

01.24~ 1500 JL473ZQ7 SC6478 PN8024 RN2815
