ROTOR DISC » RN2778V

Image Not Available

Specification

Type
Vented
Outter Ø
316
Num. of holes
5
Hole Ø:
15.2
Disc Thickness (Max)
30
Disc Thickness (Min)
28
Height
51.1
Centering Diameter
67
Pitch Circle Ø
108
Drum Ø:
140
Front/Rear
Front
Structure Material
G3000

Cross Reference

Chery
204002964AA
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHERY   »   Tiggo 9

05.23~ 2000 SQRF4J20A T28 RN2778V PN8802 RN2768 PN8048
04.25~ 2000 SQRF4J20B T28 RN2778V PN8802 RN2768 PN8048
05.23~ 2000 SQRF4J20C T26 RN2778V PN8802 RN2768 PN8048

JAECOO (CHERY)   »   J8

08.23~ 2000 SQRF4J20C T26 RN2778V PN8802 RN2768 PN8048
