ROTOR DISC » RN2776V

RN2776V

Specification

Type
Vented
Outter Ø
308
Num. of holes
5
Hole Ø:
12.8
Disc Thickness (Max)
25
Disc Thickness (Min)
23
Height
49
Centering Diameter
62.5
Pitch Circle Ø
108
Drum Ø:
145.2
Front/Rear
Front
Structure Material
G3000

Cross Reference

JAC
3500330U3400
Moskvich
3500330U3400
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

JAC   »   JS4

07.22~ 1500 HFC4GB24D RN2776V PN0791 RN2777 PN6053

JAC   »   Sehol X4

03.21~ 1500 HFC4GB24D RN2776V PN0791 RN2777 PN6053

MOSKVICH (AZLK)   »   3

11.22~ 1500 HFC4GB24D RN2776V PN0791 RN2777 PN6053
