ROTOR DISC » RN2769

Image Not Available

Specification

Type
Solid
Outter Ø
295
Num. of holes
5
Hole Ø:
13.2
Disc Thickness (Max)
10
Disc Thickness (Min)
8
Height
31.3
Centering Diameter
65.5
Pitch Circle Ø
108
Drum Ø:
144
Front/Rear
Rear
Structure Material
G3000

Cross Reference

Chery
J60-3502075EV
KAIYI
J60-3502075EV
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHERY   »   Arrizo 6

11.20~ 1500 SQRE4T15C VDC21B RN2575V PN0838 RN2769 PN8005

KAIYI   »   E5

10.21~ 1500 SQRE4T15C GS11 RN2575V PN0838 RN2769 PN8005

OMODA (CHERY)   »   S5

11.20~ 1500 SQRE4G15C M1DFL2 RN2575V PN0838 RN2769 PN8005
11.20~ 1500 SQRE4T15B M1DFL2 RN2575V PN0838 RN2769 PN8005
11.20~ 1500 SQRE4T15C M1DFL2 RN2575V PN0838 RN2769 PN8005
