ROTOR DISC » RN2767V

Image Not Available

Specification

Type
Vented
Outter Ø
316
Num. of holes
5
Hole Ø:
15.2
Disc Thickness (Max)
28
Disc Thickness (Min)
26
Height
50
Centering Diameter
67
Pitch Circle Ø
108
Drum Ø:
140
Front/Rear
Front
Structure Material
G3000

Cross Reference

Chery
204001529AA
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

EXEED (CHERY)   »   RX

02.23~ 2000 SQRF4J20C T22 RN2767V PN8802 RN2768 PN8048

EXEED (CHERY)   »   TXL

07.23~ 1600 SQRF4J16D M32T RN2767V PN8802 RN2768 PN8048
07.23~ 2000 SQRF4J20C M32T RN2767V PN8802 RN2768 PN8048

EXEED (CHERY)   »   VX

07.23~ 2000 SQRF4J20C M36T RN2767V PN8802 RN2768 PN8048
