ROTOR DISC » RN2762

Image Not Available

Specification

Type
Solid
Outter Ø
314
Num. of holes
5
Hole Ø:
15
Disc Thickness (Max)
12
Disc Thickness (Min)
10
Height
32.1
Centering Diameter
62.1
Pitch Circle Ø
108
Drum Ø:
141.1
Front/Rear
Rear
Structure Material
G3000

Cross Reference

JETOUR
204004879AA
JETOUR
F26-3502075
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

JETOUR   »   T1

01.25~ 2000 SQRF4J20B T1L RN2761V PN8802 RN2762 PN8048

JETOUR   »   T2

09.23~ 2000 SQRF4J20 T1J RN2761V PN8802 RN2762 PN8048

JETOUR   »   Traveller

09.23~ 2000 SQRF4J20 T1J RN2761V PN8802PN8061 RN2762 PN8048PN8062
