DRUM BRAKE » DN1135

Image Not Available

Specification

Outter Ø
314
Num. of holes
5
Hole Ø
13
Centering Diameter
67
Height
80
Pitch Circle Ø
114.3
Drum Ø
270
Structure Material
G3000

Cross Reference

CHANGAN
3502011-AT01
CHANGAN
3502011-BJ01-AA
CHANGAN
G101040-0100
CHANGAN
G101040-0100-B1
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHANGAN   »   Grand Van Turismo

01.15~ 1500 4G15S PN3271 DN1135 FN0795
